FLOOR HATCH ALUMINIUM 800X1720MM MULTIPART CASTABLE

BVA-MULTI 80X172 ,

Access cover, aluminium. 2- or 3-sections in a row. Equipped with seal, but not completely gas- and waterproof. For in- and outdoor use. Load endurace 125kN.

Description

Access cover, aluminium. Frame is extruded aluminium and the cover is made of aluminium plate. Cover is not fully gas- and Waterproof. Some water might drip through, if exposed underwater for long periods. Conical design and lifting key makes it easier to open the cover. Thanks to the small angles and accurately dimensioned edge structure, the cover is almost unnoticeable in the ground after installation.The door is fitted with internal reinforcing that improves its load endurance. Particularly suitable for places with very high requirements regarding the appearance of the cover’s visible edge in indoor use or when the floor requires grinding (e.g. floors with parquet). A patented detachable middle round makes it possible to open the whole length of the cover. Load endurace 125kN.

Additional information
Waterproof

Yes

Load capacity

125 kN

Width C x D

800 x 1720 mm

Width A x B

920 x 1840 mm

Manufacturers website

https://www.hago.at/en/products/details/bva-ra-aluminium.html

Gas proof

Yes

Locking type

Pultti
