Access cover ,made of 2mm thick stainless steel ,grade 304.Whole structure is passivated after welding.Gas and water-proof access cover which is manufactured with accurate dimensions.The special seal withstands chemicals well.The conical design and lifting key make it easier to open the cover. Thanks to the small angles and accurately dimensioned edge structure, the cover is almost unnoticeable after installation.The cover has reinforcing that improves its load endurance.For projects which are demanding access covers with high corrosion resistance or better hygiene, such as foodprocessing premises or hospitals.Load endurance 125kN.Fire-resistance rating EI30
FLOOR HATCH STAINLESS STEEL 800X800MM EI30 CASTABLE
Access cover,stainless steel AISI304.Gas- and waterproof.For in- and outdoor use.Load endurace 125kN.EI30
Description
Additional information
Load capacity | 125 kN |
---|---|
Width C x D | 800 x 800 mm |
Width A x B | 935x 935 mm |
Fire protection | EI30 |
Manufacturers website | https://www.hago.at/en/products/details/bve-stainless-steel.html |
Locking type | Pultti |
Waterproof | Yes |
Gas proof | Yes |
Weight | 30 kg |
Height | 75 mm |
